RF NETWORK PLANNER – signal coverage tool for indoor wireless networks

RF Network Planner V2.6.4

Visualize and estimate RF signal coverage for indoor wireless networks with ease.

Why You’ll Love RF Network Planner

        ⚡ Lightning-Fast
        Trace walls and generate heatmaps in seconds.

        🔍 Clear Insights
        Multiple propagation models and 3D views for precise planning.

        🎯 Real Accuracy
        Real-world scaling with two-click measurement tools.

        📤 Effortless Exports
        One-click export to PNG, SVG, GLB, STL, and CSV formats.

Powerful Features

Floor Plan Drawing

Draw walls or import SVG floor plans for seamless planning.

AP Placement

Position multiple Access Points with custom power, gain, and height.

Heatmap Analysis

Generate signal strength, SNR, interference, or ray-tracing heatmaps.

3D Visualization

Toggle between 2D and 3D views for comprehensive coverage visuals.

Real-World Scaling

Accurate distance measurements with intuitive scale tools.

Project Exports

Save and share projects, export images, models, and data files.

Walls Module Access

Instantly trace walls, refine your plan in 2D, and export a 3D model—no CAD skills required.

Walls Module

Interface Overview

Menu & Toolbar: Quick access to file operations and analysis controls.
Project Panel: Configure name, frequency, and models.
Main Canvas: Draw walls, place APs, and view live heatmaps.

AP Properties: Adjust TX power, gain, and orientation.
Analysis Panel: Select heatmap type, resolution, and thresholds.
Info Bar: Coordinates, zoom level, and undo/redo status.
